- <table><tbody><tr><td>Builder:</td><td>Lürssen</td></tr><tr><td>Year/Refit:</td><td>2010/2021</td></tr><tr><td>Loa:</td><td>60.00m (196.86 ft)</td></tr><tr><td>Beam:</td><td>11.43m (37.50 ft)</td></tr><tr><td>Draft:</td><td>3.50m (11.50 ft)</td></tr><tr><td>Classification:</td><td>Lloyd’s, MCA Compliant</td></tr><tr><td>Gross tons:</td><td>1,218 Tons</td></tr><tr><td>Designer:</td><td>Espen Oeino</td></tr><tr><td>Naval architect:</td><td>Lurssen (Germany)</td></tr><tr><td>Interior designer:</td><td>FM Glade Johnson Design (USA) / Kemble Interiors (USA)</td></tr></tbody></table><table><tbody><tr><td>Cruise speed:</td><td>12.04 Knots (approx)</td></tr><tr><td>Maximum speed:</td><td>16.0 Knots (approx)</td></tr><tr><td>Range:</td><td>5,000 nm (approx)</td></tr><tr><td>Fuel capacity:</td><td>Approx 159,200 liters</td></tr><tr><td>Water capacity:</td><td>43,200 liters</td></tr><tr><td>Lube Oil:</td><td>1,000 liters</td></tr><tr><td>Watermakers:</td><td>28,000 liters</td></tr></tbody></table><table><tbody><tr><td>Fuel:</td><td>DIESEL</td></tr><tr><td>Steering:</td><td>Rolls Royce Electro‐hydraulic steering gear rotary vanes with (2) rudder actuators and electrical synchronization is foreseen</td></tr><tr><td>Stabilizers:</td><td>Quantum Active and Zero Speed</td></tr><tr><td>Gearboxes for Main Engines:</td><td>Reintjes 4:1 ratio</td></tr><tr><td>Drive:</td><td>Piening-Fixed pitch propellers</td></tr></tbody></table><p>Sleeps up to 12 in the Owner’s party in 6 staterooms plus crew accommodations for up to 15 in 8 cabins </p><p>General</p><p>Sleeps up to 12 in 6 staterooms, Main Salon is flushed with natural light and comfortable textures. The modern combination of handcrafted woods, contrasting fabrics and expert lighting make this a grand room for social gatherings. Lighting, window treatments and audio visual systems are all controlled with iPad integrated remote controls.</p><p>Owner</p><p>The full beam master suite, located on the main deck,is flooded by natural light from 6 large oval windows highlighting a generous seating area and stately king sized mattress in black beauty anigre frame. A Sony 70” LED HD TV provides access to movies onboard and expertly designed lighting provides a rich and exotic ambiance. The en suite master bathroom includes a Jacuzzi tub with an inviting décor of dark handcrafted wood and marble flooring framing dual vanities. The aromatherapy shower is big enough for two.</p><p> </p><p> </p><p>Galley</p><ul><li>Cooking Equipment:</li><li>(2) Rational steam ovens (2016)</li><li>2 Burner induction (2016)</li><li>Miele microwave oven</li><li>Grill and deep fryer New (2016)</li><li>Overhead exhaust</li><li>Compactor</li><li>Refrigeration/Freezer:</li><li>Foster refrigerators</li><li>Dishwasher:</li><li>Miele dishwasher</li></ul><p>Laundry Equipment</p><ul><li>Miele Pro Washer and Dryer</li><li>(2) Meile PW 6055 dryers</li><li>Miele 7136 washers</li><li>Miele roller press iron HM 21-140 </li><li>Stainless steel sink</li></ul><p>Navigation Systems</p><p>Communication Systems SATcom:</p><p>SATcom: Thrane & Thrane; (2) Sailor TT‐3000 ELRIT Mini‐C
- Telephone System: Cisco BE 6000
- Fleet Broadband: (2) Thrane & Thrane Sailor 500 Fleet Broadband
- VHF: Raytheon‐ Thrane & Thrane RT5024/5020 DSC
- Cellular Phone System: Erikson</p><p>Intercom: Dynacord Pro Matrix DPC 4520/Phontech talkback CIS 3101</p><p>MF/HF Radiotelephones: CU5100 Raytheon‐Thrane & Thrane </p><p>Satellite TV: KVH Trck Vision HD11 (2016) VSAT antenna Sailor 9000 (new 2019)</p><p>Navigation Systems Radar: (1) NSC 25/36 900‐025‐027; (1) NSC 450‐033‐035 chart radar; Raytheon, (1) X Band, (1) S Band </p><p>Gyrocompass: (2) Anschutz (Raytheon) standard 22 </p><p>Magnetic Compass: Raytheon (Sonde) Cassens & Plath 11 & 12 </p><p>Auto Pilot: Anschutz Nautopilot NP 2015 </p><p>Depth Sounder: Furuno FE‐800 dual frequency display 50/200 kHz </p><p>GPS: (1) PSC GPS‐receiver, type R4</p><p>AIS:</p><p>(2) Saab R4 navigation system </p><p>• Set consisting of (1) control display unit with power/data cable with bracket for table/wall and frame for flash mounting</p><p>BNWAS:</p><p>• Besecke ‐ beWatch </p><p>• (1) GPS antenna </p><p>• (1) GPS receiver unit with cable </p><p>• (1) Alarm relay </p><p>• (1) PCS DGPS‐receiver, type R4 </p><p>• Set comprising of: </p><p>• (2) control display unit with power/data cable with bracket for table/wall and frame for flush mounting </p><p>• (2) DGPS antenna </p><p>• (2) DGPS receiver unit with cable </p><p>• (2) Alarm relay </p><p>Ships Computer:</p><p>• (6) Dell computers located in the ship’s office, crew mess, and control room</p><p>Wired Network:</p><p>• CAT 6 throughout</p><p>Wind/Speed Log:</p><p>• Skipper EML 224 EML 224 two axis water track log, single bottom gate valve Speed range + / ‐ 40 knots with NMEA 0183, pulse and analogue Output (2x serial, 3x pulses, 3x analogues, 1x VGA) Operator / Display unit with 10.4“ color screen 115/230VACor24V DC supply Comprising: 1 Display / Operator unit with integrated colour TFT‐display 1 Interface installation kit 1 mounting set for EML 224, single bottom with sea valve (DNV approved, GL, LR or ABS with extra charge) 1 transducer with 40m cable gate valve version</p><p>Navtex:</p><p>• (1) Set NCR‐333 NAVTEX receiver </p><p>• (1) Navtex antenna</p><p> </p><ul><li>CCTV System:LAN based camera server</li><li>Cameras:(3) Fixed, VD-Ship’s entry surveillance\\Axis-Q6125-LE (2019); (1) Pan/tilt, VD-deck surveillance </li><li>Monitors: One central video storage unit providing 24k hour storage capacity for video signals of all cameras detailed later at full PAL resolution and frame rate</li><li>Marioff (3) HiFog</li><li>(2) Manually operated call points</li><li>(23) Fire hydrants</li><li>(15)Fire hoses with nozzles</li><li>(5) Emergency escape breathing devices</li><li>(1) Portable foam applicator</li><li>(4) BA sets and fire suits</li><li>(2) International shore connections</li><li>Fire Extinguishers:(35) (Foam, CO2, powder)</li><li>Alarms: Tyco alarm monitoring</li></ul><p>Safety Equipment:</p>(2) Life rings(2) Life rings with line(2) Life rings with light(2) Life rings with light and smoke(1) Globalfix Pro GMDSS EPIRB(2) McMurdo S4(2) Red rockets(10) Handheld(2) Orange smoke<p>Life Jackets & Medical Equipment:</p><ul><li>(81) Adult / (3) Oversize and (3) Child</li><li>(28) Adult / (2) Oversize and (3) Child/li> </li><li>(3) Eye wash stations</li><li>(3) Medical lockers</li><li>(1) Tempus IC Machine</li><li>(1) Defibrillator</li><li>(1) Oxygen kit</li><li>(1) Oxygen machine</li><li>(2) Stretchers</li><li>(1) Pediatric kit</li><li>(1) (2) Crash packs</li></ul><p>Anchor Windlass System:</p><ul><li>Steen 2 X Vertical Windlasses</li></ul><p>Aft Warping Capstans:</p>Steen 2x Vertical Capstans<p>Anchors:</p>(2) Schmitt stockless high holding, 580 kg<p>Anchor Chain:</p>Galvanized anchor stud link chain- (6) Shots port; (6) Shots Stbd<p>Boat Crane and Davits:</p>Rescue (SOLAS) crane on foredeck-Hymartec Hydraulics 1000 kg One in number gantry crane comprising two bridle beams with rollers installed in the ceiling of the tender garage on Lower Deck in order to launch and retrievethe tender boats and water toys to both sides (PS and SB). Crane beams are of stainless steel.<p>Passerelle:</p>Hydro control / Hymartec
