- Length: 55m (180’ 6”)
- Beam: 9.4m (30’ 11”)
- Draft: 3m (9’ 11”)
- Build Year: 2011
- Refit Year: 2022
- Builder: Heesen
- Naval Architect: Vripack / Heesen
- Exterior Designer: Omega Architects
- Interior Designer: Mark Berryman (refit) / Ken Freivokh & Michela Reverberi (original)
- GT: 781
- Hull: Aluminium
- Superstructure: Aluminium
- Hull Colour: Navy Blue hull / White superstructure
- Hull Configuration: Semi-Displacement
- Flag: Cayman Islands
- Classification: Bureau Veritas
- MCA Compliant: Yes
- Heli: Heli-Capable – handles a Eurocopter EC 135 or similar
- Main Engines: 2 x MTU 20V4000M93L, 4300kW at 2100 rpm each
- Fuel: Diesel
- Water: 30,000 litres (7,925 US Gallons)
- Holding Tanks: 9843 ltrs
- Cruising Speed: 17 knots
- Maximum Speed: 25 knots
- Number of Cabins: 6
- Guests: 12
- Sleeping Configuration: Main Deck: 1 x Master Cabin (King), 1 x Double Cabin / Lower Deck: 1 x VIP Cabin (Queen) –> convertible into 2 x Double cabins, 1 x Double Cabin, 1 x Twin Cabin (2 x single beds)
- Crew Cabins/Berths: 6 crew cabins + 1 captain cabin / 13 crew total
- Main Engines
- Engine Make/Model: 2 x MTU 20V 4000 M93L Diesel @ 4,300kW
- Engine Hours: STBD Engine – 6558h , PORT Engine – 9627h
- Gearboxes for main Engines: 2 x ZF 23560C + ZF Autocontroll
- Drive: Twin Screw Propeller
- Generators & Electricity
- Generators: 2 x 175kW Kilo Pak, 1 x 80kW Kilo Pak
- Generator Hours: FWD Generator – 592h , AFT Generator – 27139h
- Generator Fuel Consumption: 400 L/day
- Electricity: 400V
- Shore Power: Converter 110v/240v/400v 50-60Hz 100kw
- Batteries
- Main Engine Starting: PORT Engine - 6 x 12 V 50 Ah batteries , STBD Engine - 6 x 12 V 50 Ah batteries.
- Service Battery - 6 x 12V 200 Ah batteries paralleled to give 24V 600 Ah capacity.
- Emergency: Capacity 400Ah / Emergency Start Batteries: EMG 1 and EMG 2
- Air Conditioning:
- Type: Chiller unit – 2022Conversion to MC3-CH-C H&H . with 2 Fresh air control units with conversion to MC3-FA-C. Located AHU1 in Bridge Deck Port side and AHU2 FWD Bridge Deck.
- Other Machinery
- Trim Tabs/Stabilizers: VT Naiad 820 with 2 fins of 4,66m2 – Zero Speed
- Bow Thruster: HRP 120Kw, hydraulically driven
- Steering System: Sperry Marine System
- Fuel Separator & Filtration: Alpha Laval
- Sewage System: Hamann treatment
- Fresh Water System: HEM, cold water system
- Bilge Water Filtration: RWO
- Lube Oil Capacity: 2,000 litres (528 US Gallons)
- Waste Oil Capacity: 2,000 litres (528 US Gallons)
- Elevator: Yes, serving the lower deck, main deck and bridge deck. Does not go up to the sundeck
- COMMUNICATION SYSTEMS
- SAT Com: Inmarsat C
- Telephone System: Panasonic
- SSB: Commander 1500
- VHF: Sailor RT 5022 DSC
- Cellular Phone System: Gigaset
- Intercom: SQS PS – 1650H
- NAVIGATION SYSTEMS
- Radars: 1 x Furano Band X, 1 x Furano Band S
- Gyrocompass: Sperry Marine SN. 1032-125
- Magnetic Compass: Northrop Grumman Sperry Marine
- Auto Pilot: Sperry Marine Navpilot 4000
- Depth Sounder: Furano FE-700
- Night Vision: FLIR M400
- GPS: SAAB
- Plotter: ECDIS Chart
- Wind/Speed Log: Furano DS80
- Navtex: Furano NX-700
- Dual TimeZero with intergrated WASSP system
- ENTERTAINMENT SYSTEM – Centralised Controller using Crestron GUI on iPads
- AV Equipment
- Apple TV, Plex Server, Kaleidoscape, Direct TV, and IP TV
- Main Salon: TV 100” Sony FW-100BZ40J. RGB Lighting.
- BD Salon: 85” Sony FW-85BZ40H/. RGB Lighting.
- Master stateroom: 75” Sony FW-75BZ40H/. RGB Lighting.
- Guests’ staterooms: 43” TVs Sony.
- Sundeck: 2 x 50’’ TV Sony
- Aft deck: 50’’ TV Sony. RGB Lighting. 4 x Disco lights with Sound 2 light feature.
- 2 x Starlink Maritime antennas.
- VSAT: 2 x Intellian V130NX, GEO, MEO, LEO upgradable.
- TVRO: 1 x Intelliant130W.
- 4G/5G: 1 x BlueSIM dome connected via a balance router.
- Bowers & Wilkins speakers, James Loudspeakers.
- Party Mode and Karaoke System – with integrated sound, microphone, visual and lighting.
- Cat7 cabling laid for any future upgrades
- Main Galley Equipment
- Cooking Equipment: Leventi Oven
- Deep fryer: Pakojet
- Steam oven – 2 x Convotherm Combi Steamer OES6.10 mini
- Cooktop: 4x Induction cooktop MS-I-20EM
- Microwave: Panasonic NE - 1643
- Refrigeration/Freezer: Heinen Hopman
- Dishwasher: Miele
- Dumbwaiter: BKG serving the lower deck, main deck and bridge deck
- Crew Galley/Mess Equipment
- Microwave : Miele
- Dishwasher : Miele
- Hot water boiler
- Water Filtration system
- Other Equipment:
- Coffee Machine: Juia Giga 10
- Wine fridges: 1x Eurocave V-PREM-L , 6 x mQuvee WineCave 800 60D
- Ice-makers: 5x Hoshizaki IM-30CWNE-HC
- Laundry Equipment
- Washing Machine: 3 x Miele Pro
- Tumble Dryer: 3 x Miele ProTenders: 2024 VIKAL 7.5m limo tender / 2022 5.5 Castoldi Jet rescue tender
- Dive Gear: Onboard dive compressor + full dive gear for 12 guests
- Recreation: 4 x 2024 SeaDoo GTX300 Jet Skis / 3 x 2022 Seabob F5SR / 4 x Lift Electric E-Foil boards / 2 x Ravic Awake S Electric Surfboards / Waterskis / Wakeboard / Snorkelling gear / Full fishing gear on mothership and tender / Tuna tower and outriggers
- Inflatables: Custom dock/waterpark for 4 jet skis, 4 electric boards, seabobs, kayaks, SUPs / Custom inflatable prism tower / Custom inflatable bar/lounge area / Donuts
- Exercise Equipment: Fully equipped with step machine, cross trainer, Technogym balls and weights set, resistance cables, yoga mats.
- Other: Crane with SWL of 1.5 tonnes
- Anchor Windlass: Staal Art CAR 37-24ED
- Aft Warping Capstans: Staal Art
- Anchors: Ship Equipment Center 373Kg
- Anchor Chain: Rema Holland 24mm; 2 x 5 shackles
- Boat Crane and Davits: Hydromar
- Passerelle: Hydromar
- Swimming Platform: Hydromar
- Swim Ladder: Hydromar
- Side boarding ladder: Hydromar
- Underwater lights: Oceanled (fitted by Huisman)
- Searchlights
- Garbage Fridge
- Security Equipment
- CCTV System: Samsung SHR-6162
- Cameras: Flir
- Monitors: Hatteland
- Fire Fighting Equipment
- Fire Control System: Hi-Fog
- Fire Extinguishers: Jockel
- Alarms: Tyco Minerva T2000
- Safety Equipment
- Life Rafts: 4 x Zodiac ZMEC 16
- Life Rings: Life jackets, Immersion suits, Lifebuoys
- EPIRBS: Jotron + SART Jotron T20
- Flares: Comet
- Medical Equipment: Full commercial
- Spa Equipment
- Hammam: KLAFS
- Sauna: KLAFS
- Massage Room: 1x Fixed massage bed, 1x Foldable massage bed , 2x Massage chairs
