ADVANCE PACKAGE
ELECTRIC WINCHES
ADDITIONAL CONTROL FOR ELECTRIC SEARCHLIGHT
DECOR UPGRADE
SPARE CONDUITS
CHAINCOUNTER IN MAIN HELM
PREDISPOSITION FOR WATERMAKER
DOUBLE RACOR FILTERS
MIELE APPLIANCES
MESH COVERS FOR WINDOWS
MANUVERING JOYSTICK
SEAKEEPER STABILIZERS
TELESCOPIC GANGWAY
CREW CABIN WITH ONE BED
VANITY FURNITURE IN MASTER CABIN
GLENDENNING CABLE MASTER
TWO UNDERWATER LIGHTS ON TRANSOM
SPREADER LIGHTS ON AFT FLY N.6
SUN SHADE SAIL ON BOW WITH REMOVABLE POLES
ADDITIONAL SET OF ZINCS
RAYMARINE VIDEOCAMERAS (NR.3)
TEAK ON FLYBRIDGE
TEAK ON SIDE DECKS
MOSQUITOS NET FOR PORTHOLES
STERN TEAK STEPS
ADDT\'L SEAKEEPER CNTRL STATION ON FLY
WASHER/DRYER (COMBO UNIT)
EXTENDED DINETTE HI-LO TABLE - AUTOMATIC
CO-PILOT SEAT IN MAIN HELM
FABRIC CURTAINS IN CABINS
SET OF TOWELS FOR ONE PERSON WITH PATTERN (EACH)
FLAGPOLE
ICEMAKER ON FLY
SET OF LINEN FOR CABINS
SET OF LINEN FOR CREW CABIN (TWO BEDS)
COCKPIT FURNITURE WITH REFRIDGERATOR
GALLEY TOP IN QUARZITE - STATUARIETTO
COCKPIT TABLE W/CORIAN FRAME & SYNTHETIC MARBLE INSERT
WOODEN FLOOR IN SALON
WOODEN FLOOR IN DINETTE
COCKPIT CHAIR (MOD.OSKAR)
SAFE IN MASTER CABIN
WINECOOLER IN GALLEY
FOREDECK LOUNGE W/CONVERTIBLE BENCH/SUNBED IN BATYLINE FABRIC
LOUNGING ON AFT FLY: L-SHAPED SOFAS PLUS LOVE SEAT IN BATYLINE
FABRIC & COFFEE TALBE W/CORIAN FRAME & SYNTHETIC MARBLE INSERT
KYRA PIETRA A000127509 SIMIL LEATHER ON MAIN DECK CEILING
COFFEE TABLE IN SALON
NIGHTSTANDS JEWELRY BOXES - BY ACHILLIE SALVAGNI
UPGRADE EXTERNAL CUSHIONS IN BATYLINE FABRIC
CO-PILOT SEAT ON FLY
FLYBRIDGE TABLE W/CORIAN FRAME & SYNTHETIC MARBLE INSERT
PAINTED BOOT STRIPE
AUDIO/VIDEO PKG W/TRACVISION SAT TV ANTENNA & DECODERS
ELECTRIC AWNING IN COCKPIT
HANDRAIL IN STAIRS AREA WITH SIMIL LEATHER INSERT
COMPASS OF FLY
RAYMARINE PLATINUM PACKAGE
STERN THRUSTER
TOILET W/BIDET FAUCET FEATURE
HARD TOP
DELUXE LIGHTING PACKAGE
BARBEQUE ON FLY
ELECTRIC AWNING ON FLYBRIDGE
PEACE OF MIND WARRANTY
Flybridge
Access via flybridge ladder in GRP, with teak steps
Anti-slip treatment on flybridge flooring
Aluminum hatchway (hinged opening in plex)
Front flybridge screen in smokey Plexi- glas and stainless steel
\"C\"-shaped sofa for six people on port side, with teak table
Sunbed area, bow starboard side
\"L\"-shaped cabinet on starboard side with fridge
GRP roll bar with blind windows on the external sides
Stainless steel handrails
Helm seat with pedestal and height and horizontal adjustment
Stainless steel steering wheel painted white, and height-adjustable steering system
The wheelhouse equipment includes:
Raymarine Bronze Package
Engine display
Thruster control
Rudder
Chain meter counter
Engine levers
Panel with main control switches
VHF
Bow / walkarounds
Anchor chain housing
Pulpit
Two bow cleats
Two electric windscreen wipers / windshield washers
PVC rub-rail with knurled stainless steel section
GRP walk arounds with non-slip treat- ment
Anchor locker
Flat windows in toughened glass in the GRP (mirror finish)
Seating area with cushions
Two midship cleats
Navigation lights
Side wording
Two refueling plugs with protection cover
One fresh water filling on starboard side (anchor locker area)
One black water outlet on port side
Side hatches
Bow lockers
Cockpit / platform
Compass
Engine display
Engine starting buttons
Thruster control
Rudder
Engine levers
Panel with main control switches
VHF
Integrated stainless steel aft chocks
Two stern cleats
Saloon access door in black-painted stainless steel and tempered glass, with three panels
Crew cabin access door (optional) from the transom
Swimming ladder in stainless steel and teak that can be opened under the hatch
Shore power socket(s)
Shower
Cockpit in teak
Teak platform
Cockpit bench lockers
Cockpit lights with dimmer
Locker with access from hatch on platform
INSTALLABLE TENDER (OPT):
MAXIMUM DIMENSIONS OF TENDER - PLATFORM: 3.35 x 1.65 m (10\'11\'\' x 5\'5\'\')
MAXIMUM DIMENSIONS OF TENDER - FLYBRIDGE: 2.75 x 1.50 m (9\'0\'\' x 4\'11\'\')
LIFT PAYLOAD EXCLUDING GRP, TEAK AND LADDER: 390 kg (859.80lb)
DAVIT PAYLOAD: 250 kg (551.16lb)
RECOMMENDED TENDER -
PLATFORM: Pirelli J33
Wheelhouse
Adjustable helm seat for one person
Height-adjustable steering system
Electrically openable wheelhouse window
The wheelhouse equipment includes:
Raymarine Bronze Package
Saloon / Dinette / Galley
Saloon
Sofa for six people on port side
Carpet
LED lighting
two seater sofa on starboard side
Saloon door curtain in fabric
Roman-type curtains in fabric
Radio CD with remote control and two loudspeakers
Provision for TV system
Dinette
Dining zone with two opposed sofas
Carpet
LED lighting
Table with fixed plane (from Serial No. 426)
Galley
Ceramic glass four-hob range, 50/60 Hz
20 l (0.71 cu.ft) microwave oven + grill
Wooden worktop
Hood above the range
185 l (6.53 cu.ft) fridge, 44 l (1.55 cu.ft) freezer
Wood essence floor
Owner’s cabin
Located midship
Double bed with locker accessed from above
Mattress, pillows and bedspread
Chest of drawers
Carpet
Wooden Venetian blinds
Doors and frames in wood essence
Direct access to owner\'s head
Reading lights
Suitable for TV installation
Large hull windows with built-in port- light
Owner\'s head
Access from owner\'s cabin
Separate shower
Shower column with soap dish and mixer taps
Washbasin with top
Synthetic teak floor
TECMA toilet
Round portlight
Wooden Venetian blinds
Head accessories
Wall unit above washbasin with mirror
Large storage area behind toilet
Air extractor
Guest cabin
Located on starboard side
Fixed single beds
Central bedside table
Wardrobe on bulwark
Carpet
Wooden Venetian blinds
Fix window with openable round port- light
Reading light
Doors and frames in wood essence
Mirror inside the wardrobe
Guest / daily head
Access from corridor
Shower with panel
Shower column and mixer taps
Washbasin with top
Round portlight
Synthetic teak floor
TECMA toilet
Roller-type curtains
Head accessories
Wall unit above washbasin with mirror
VIP cabin
Located at the bow, it is accessed via the central corridor
Openable double bed
Mattress, pillows and bedspread
Wall units
One wardrobe per side
Suitable for TV installation
Panoramic windows with openable port- lights
Wooden Venetian blinds
Hatchway
Reading lights
Doors and frames in wood essence
Direct access to head
VIP head
Access from VIP cabin
Shower with panel
Shower column and mixer taps
Washbasin with top
Round portlight
Synthetic teak floor
TECMA toilet
Roller-type curtains
Head accessories
Wall unit above washbasin with mirror
Corridor
Fabric wall upholstery
Carpeted floor
LED lighting
Crew room (OPT)
Crew cabin
Access from transom, via manually moved door
One single bed (version with two beds instead of aft storage is available
Mattresses, pillows and bedspreads
Cabinet with electric panel
Wooden Venetian blinds
LED spotlights
Laminated furniture
Crew head
TECMA toilet
Sink
Mixer tap with pull-out shower head
Head accessories
Shower curtain
Shower
Mirror
Electric system
Voltage levels on board
110 V AC systems, 60 Hz
24 V DC systems power supply
24 V DC motor systems power supply
24 V DC from battery sets
12 V DC through voltage reducer
specific power supply for VHF
Galvanic current insulation
Zinc anodes
Generator
7 kW -60 Hz generator
Shore power sockets
One shore power socket 110 V - 60 A
Batteries
Six batteries for service utilities 90 Ah - 24 V - 270 Ah
Six batteries for engine start-up 90 Ah - 24 V - 270 Ah
One battery for generator 70 Ah - 12 V
All the sets are controlled via battery cut- out switches
Battery charging
One electronic battery charger 24 V - 80 A for start-up and service sets
One electronic battery charger 12 V - 10 A for generator
Electric panels
Two main DC boards, one in the engine room and the other in the saloon
Two AC boards, one in the saloon and the other in the crew cabin
Emergency panel in cockpit (with boat cut-off controls)
Power circuit breakers with fuses for protecting the utilities
Lighting
LED spotlights
Bilge system
Three automatic 24 V electric pumps - flow rate 224 l/min (59.17 US.liq.gal./min) - with possibility of manual control, located in crew cabin, engine room, owner\'s cabin. Each pump has a double high-level switch connected to an optical/acoustic alarm in the wheelhouse
Two manual pumps - flow rate 49 l/min (12.94 US.liq.gal./min) - which suck from the three watertight compartments through a flow deviator:
. one located in the cockpit, it sucks from crew cabin and engine room
- one located in the crew cabin
Emergency system for engine room bilge drainageviaderivationfromenginecool- ing pump - capacity 334 l/min (88.23 US.liq.gal./min) -
Fire extinguishing system
Controlled from emergency panel in cockpit
Engine battery cut-out
Closure of fuel delivery solenoid valves
Extractor stop
One dry chemical cylinder in the engine room
Fuel system
Two tanks, 1400 l (369.84 US.liq.gal.) each, total capacity 2800 l (739.68 US.liq.gal.), in aluminum
Refueling plugs with cover
Two refueling plugs on deck walk arounds, and two vents on bulwark
Tanks linked by a 1” coupling, and man- ual check valves
Optical level gauge on starboard tank
Status level gauge on port tank
Fuel delivery shut-off via 1” 24 V solenoid valves with remote control, or local manual valves
Water/diesel separators for engines (single type)
Diesel filter for generator (single type)
Fresh water system
One 750 l (198.1 US.liq.gal.) polypropylene tank
One water fill cap on starboard walk around and a vent on port side bulwark
Pressure pump
One 60-liter (15.84 US. liq.gal.) water heater with 220 V (or 110 V) electric heating
System that can be isolated by ACORN manifolds
Hot and cold water line in the galley and all the heads, via single control mixer taps
Cold water line in engine room, on flybridge, and on stern platform
Black water system
TECMA toilet
Toilet flushing system with fresh water
Black water outlets
Macerator pump
Discharge into tank
One 175 l (46.2 US.liq.gal.) polyethylene tank
Tank drainage also via suction point on deck walk around
Gray water system
One 175 l (46.2 US.liq.gal.) polyethylene tank
Head discharge into tank
Galley discharge into tank
24 V loading pump, of the membrane type with control in the wheelhouse
Engine gas exhaust system
Two engine underwater exhausts with GRP structural ducts
Minimum bypass on bulwark
Stainless steel manifolds (insulated)
Seawater system
Two 3\" engine seawater intakes, with shut-off valve and metal mesh filter
Two seawater intakes, 1” for auxiliary services (generator and A/C), with shut- off valve and metal mesh filter
Ventilation/extraction
Two air intakes with separator filters
Two 24 V extractors
Engine room
Access from cockpit
Engines assembled on a silent block
Sound-proofing
Other systems
One electric steering system
Two 24 V automatic trim controllers (intruder)
Air conditioning system (OPT)
CONDARIA type - 220 V - 50 Hz
World version 72,000 BTU (+ 6200 BTU for crew cabin, OPT):
One compressor, 72,000 Btu (with inverter)
