- Sleeps 8 in 4 staterooms
- There are 3 guest cabins on the lower deck plus the gymnasium plus the owner\'s cabin on the main deck. As well as 6 guest heads and 5 guest showers.
- Crew accommodations include 7 berths, 4 heads, and 4 showers. The Captain\'s quarter is separate.
Owner\'s Suite, Main Deck Forward
A majestic full-beam stateroom forward of the main saloon on the main deck, the bedroom features a large flat-screen television and optional hydraulic balcony. Forward is the spacious en suite with his and hers washbasins and enclosed shower & stream room.
Equipment:
- BO System
- TV Screen BO
- iPod docking station
- Mini Fridge & Bar
- OCEAN AIR blinder
- Sounds System (Subwoofer)
- Escape Hatch (Floor bathroom crew, top sinks foredeck)
- Steam Shower
- Bathroom Heating Floor
- Entry walking wardrobe
- Additional sound insulation
- Balcony: (BESENZONI) full hull side split door arrangement with automatic stanchions
- Teak Inlay
Main Salon, Main Deck
An open-plan area that is the perfect meeting place for guests, the main saloon features ample seating, a rise and fall flat-screen television and hydraulic balconies.
- All Oak Panelling & Floor
- Blade Store Wood
- Fridge & Icemaker
- AV System BO
- 4 Sofas – Coffee Table
- UV Tinting on main deck saloon side windows and patio doors
- Electric Patio Door
- Full height bulwalk balcony fitted with manual stanchions
Dining Salon, Main Deck
- This area features a table that can sit twelve and benefits from an airy, light feel with proximity of the balconies.
Galley, Main Deck Forward Amidship
- Located on the main deck adjacent to the dining area, this is a fully fitted, chef-standard kitchen where all guest meals, including formal dinner parties, can be prepared with ease.
Guest Staterooms
- Port guest stateroom offers twin beds, and en suite shower room.
- Entertainment B&O IPOD Dock
- (2) Guest staterooms below deck aft with Queen Size bed and en suite bathroom, entertainment B&O IPOD Dock
- Exercise Room, Below Deck Forward Starboard:
- The Gym includes a Complement of exercise equipment
Crew Quarters Forward
- With separate circulation for the crew, the crew area is accessed through staircase from the main deck. Feature a galley and crew mess as well as Accommodation for up to eight crew.
- From aft with Jacuzzi surrounded by sunbathing beds, followed by dining table opposite to wet bar with sink & tap, fridges, Ice-crusher, grills and storage. Forward there is flybridge navigation station and access to raised pilothouse.
- The Flybridge is also equipped with recessed Flat TV screen in the mast, mist sprinklers, hard top retractable awning and aft mast retractable sun awning.
- Retractable sun awning flybridge hardtop in white
- Aft Cockpit retractable sun awning
- Fold-out wing station port side of flybridge
- MAIN ENGINES: (2) MTU 12V 4000 M93L 2 x 3460HP @ 2100 RPM
- Port Engine Hours: 1,246 (Jan 2022)
- Starboard Engine: 1,295 (Jan 2022)
- Gearboxes: ZF Marine
- Ratio: 3:286
- Drive: Shaft / TEMET 25.140mm - Propeller / NIMBRAL 5 blades
Generators
- Generator #1 (starboard) KOHLER kW65, 6,407 hours (Jan 2022)
- Generator #2 (Port) KOHLER kW65, 5,176 hours (Jan 2022)
- Generator #3 (night) KOHLER kW30,421 hours (Jan 2022)
- Output – Volts: 220/380V – 3 Phases – 50 Hz
- Generator Fuel Consumption/Day: 200L/Day
Capacities
- Fuel (including extra range tank) 28,710 litres 7,585 US gallons
- Day Tanks: 3,580 litres 947 US gallons
- Dirty Fuel Tank: 155 litres 41 US gallons
- Fresh Water Tanks: 4,950 litres 1,307 US gallons
- Watermakers: 300 litres/hour 79 US gallons/Hour
- Lube oil: 290 litres 77 US gallons
- Waste oil: 290 litres 77 US gallons
- Bilge tank: 180 litres 48 US gallons
- Black Water: 1,350 litres 357 US gallons
- Grey Water: 350 litres 93 US gallons
Speed, Consumption, Range, and RPMs
- Economical: 12/13 knots, 350 L/H, 1300 NM @ 1200 RPM
- Cruising: 17 knots, 550 L/H, 853 NM @ 1800 RPM
- Maximum: 27 knots, 1200 L/H, 621 NM @ 2200 RPM
Air Conditioning System and Compressed Air System
- Air Conditioning: MARINE AIR (4) Chilled Water System, BTU: 480.000
- Fresh Air System: (2) 24.000 BTU (including Gym room)
- Compressed air system: BAUER Junior II compressor & workshop compressor
- Shore Power – Volts: 220/380V – 3 Phases – 50 Hz
- Converter – Incoming Volts: 380V
- Shore Power Converter (2012): ASEA converter AC90V – 3
- Main Engine Starting batteries: (8) 24V 105Amps
- Service batteries: (6) GEL 24V 105Amp
- Emergency batteries: (4) 24 Volts 105 Amp
- Radio batteries: (2) 24 Volts 105 Amp
- Emergency Lights batteries: (2) 24 Volts 105 Amp
- Frequency Converter: (1) POTENTIA PP95-1-3/3 Modular
- Battery Charger: NEWMAR: Service (67A), Engine (67A), Emergency (44A), Radio (20A)
- AC Supply & Distribution
- Connection to shore power through Glendenning 100amp 20mt master cable. Seamless transfer switching between generator and shore power
- Marine Personal Assistant (M.P.A) control of tank levels, breaker status, alarm activation and monitoring, pump controls, bilge and fire information and all electrical load management
- WATERMAKER #1: HRO 180L/H 2 membranes Horizon Seafari H1212101480
- WATERMAKER #2: HRO 120L/H 1 membrane Horizon Seafari H1212000630
- Stabilizers (at anchor): ABT TRAC 370 fin Stabilizer 21.5 Sq ft (type 16X)
- Bow Thruster: ABT TRAC 20 100HP (American Bow Thruster)
- Stern Thruster: ABT TRAC 65HP
- Steering System: HYDRIVE
- Emergency Steering System: MANUAL, 220V/24V
- Helm/Control (4) Stations: Wheelhouse – Fly bridge – (2) Wings
- Sewage System: HAMANN
- Black Water System: TECMA 24V
- Discharge/macerator pump: 220/380 V AC – 140l/min
- Fresh Water System: (2) GIANNESCHI
- Water mist system: Fly bridge hardtop – 8 pcs
- Steam shower Owner: Kohler 7kW
- Grey Water System: TECMA wastewater pumping units
- Discharge/macerator pump: 220/380V AC – 160 l/min
- Fuel Filtration: ALFA LAVAL MIB 303S-13 7500T/Min 760 lt/hr
- Extraction & Ventilation System: 165m3/mn A60 approved marine fire dampers
- Power pack: (2) pumps 220V AC, Oil Tank Capacity up to 100 litres
- Auxiliary Hydraulic Pack: Tender garage door, Tender garage door locking pins, Trim tabs, Hydraulic Tender Recovery Winch, Hydraulic Rise & Fall Bathing Platform, Bulwark, Balconies and locking cylinders, Master Stateroom Balconies and locking cylinders
- Central Hydraulic System: American Bow Thruster bow & stern, Stabilizers, (2) Anchor winches, (2) warping capstans. (2) hydraulically driven seawater-cooling pumps.
- PTO: pump on port Generator, both Main engine, 2x 11kw AC pump
- A locally mounted manual hand pump, in the event of ships power loss, can also operate the System
Communication
- Communication System: Panasonic KX-T7730
- Satcom(s): Furuno 0560
- VHF Fixed: SAILOR RT5022 VHF DSC
- VHF Handheld: MIALANA SIMRAD GMDSS
- VHF: SIMRAD RS87 DSC VHF (wheelhouse, flybridge helm, crew mess, emergency steering)
- VHF: Sailor RT5022 repeater hand set at the fly helm
- Loudhailer: (1) Hailer horn connected to SIMRAD RS87
- Telephone System Two shoreline: (1) phone and (1) fax connected to PABX
- PABX telephone: B&O telephone Wheelhouse, Captain’s cabin, Main Saloon, Master Stateroom, Starboard twin guest cabin, Port twin guest cabin
- Emergency Radio Beacon: SIMRAD EP50 EPIRB & SART SIMRAD SA50
- Communication Equipment: (2) handheld VHF SIMRAD AX50 GMDSS
- Thrane & Thrane V7 broadband
- Fixed data points
- Wireless Access Points
Navigation
- Sat TV: (2) Seatel 4004
- Radar: Furuno FAR2117BB 96 Nm
- Radar: Furuno 1944BB 72 Nm
- Autopilot: SIMRAD AP 50 Autopilot with RF45X Rudder ref
- Gyrocompass: COMNAV DV2-FURUNO Satellite Compass
- Compass: FURUNO SC50 Satellite compass interfaced to autopilot
- Compass: Richie COMPASS
- Displays wheelhouse: (3) 19’’ Hatteland screen
- Display Flybridge: (2) 15’’ Hatteland screen
- Radar integration for Transas, AIS class A transponder, ARPA Integration for Transas
- Navigation display: Signal from Transas to be fed on Saloon TV only
- Satellite System: THRANE & THRANE fleet 33 phone system
- Searchlight: (1) 24V Sanshin remote searchlight
- Windscreen Wipers: (5) pantograph with screen washers
- Air Horn: Kahlenberg D2 with KA500 Air Compressor
- Depth Sounders: Furuno MULTI STATION RD 30
- GPS: SIMRAD GN 33
- Navigation Display: Hatteland
- Chart Software: Transas Navisailor chart plotting bridge & flybridge
- GPS: FURUNO
- NAVTEX: FURUNO NX700
- AIS: FURUNO FAI
- Weather Fax: INMARSAT C FURUNO N700B
- Wind Indicator: SIMRAD
Flybridge Navigation
- VHF: SIMRAD RS 87 GMDSS
- VHF: SAILOR CU 500
- Autopilot: Repeater SIMRAD AP50
- Repeater: Bow & Stern Thruster Control TRAC, Hydrive Steering Control, Night Camera – CCTV – Monitor – Flir
- Search Light: SANSHIN HR 1012
- BANG and OLUFSEN system Audio Visual up throughout all accommodation
Main Deck Saloon:
- LG 4K OLED 65 Model 65E7V \"fixed\"
- Bose 38 Lifestyle surround sound-system
- Satellite decoder with local control
- iPod docking station
Owner Cabin:
- 50” LCD television
- Bose 28 Lifestyle surround sound-system
- Satellite decoder with local control
- iPod docking station
Guests Double Cabins (2):
- 32” LCD television
- Bose 321
- Satellite decoder with local control
- iPod docking station
Twin Cabin & Gym Room:
- 26” LCD television
- Bose 321
- Satellite decoder with local control
- iPod docking station
Sun Deck & Main Deck Aft Cockpit:
- (3) pairs Marine speaker (zoned from Main Saloon)
- (3) Bose SA2 Amplifier
- Bose PMC II remote
Main Galley appliances
- Oven: (2) MIELE M5681B 600mm
- Micro-wave: MIELE 8261SS
- Ceramic Cook top: GAGGENAU VC230
- Induction Cook top: (2) GAGGENAU VI230
- Extraction Hob: MIELE DA3190 (with upgraded metallic ducting)
- Dishwasher: MIELE Professional G7856
- Coffee Machine: MIELE CVA 5056 (Built-in)
- Wine Cooler: MIELE KWL4154 UG-1
Main Deck Saloon appliances
- Icemaker: RARITAN
- Refrigerator: MIELE K621 Ui-1 (undercounter)
- Stern Laundry appliances:
- Washing Machine: MIELE Professional PW6065
- Condenser Dryer: MIELE Professional PT7135
Crew Mess appliances
- Microwave: MIELE M8201-1
- Refrigerator: MIELE K621 Ui-1
- Dishwasher: MIELE G1162 SCVI
Flybridge wet bar appliances
- Fridge: (2) Waeco CR110
- Icemaker: RARITAN Standard
- Griddles/grill: (2) GAGGENAU VR421
- Crushed Ice Machine: (incorporated into flybridge GRP Ice Chest)
- Jacuzzi: Flybridge (seats 4 people)
- Gym: Starboard forward Cabin
- Steam Shower: Owner bathroom
- Bathrooms: All bathrooms equipped with under floor heating
- Anchor Windlass System: (2) MUIR vertical VRC 8000 HYDRAULIC
- Anchors: (2) Stainless Steel
- Anchor Chain: 190mt & 165mt, Diameter 17.5mm. Galvanised stud linked chain
- Deck Capstans: (2) MUIR VC6000 HYDRAULIC
- Stern Gangway: BESENZONI 6mt x 0.58mt extension, stainless-steel
- Underwater lights: (10) under water lights Seavision SV19 (24vdc) 80mm
- Additional set of Mooring: (4)
- Bow Fairleads: (4) with integral rollers
- Air Conditioning air handler upgrade to quieter running AHDC units
- Antifouling upgrade
- Auto Troll option for Transmissions (Trolling for gearboxes)
- Balcony - Forward Main Deck Stateroom Portside
- (2) Balcony - Amidships Main Deck Saloon
- Oak interior wood finish
- Custom Refrigeration in Main Galley
- Deck and Superstructure molded in Ral White
- Misting system for flybridge
- Forward long-range fuel tank (5,150 litres)
- Frequency converter ASEA
- Fuel cleaning centrifuge Alfa Laval
- Generator upgrade
- GRP Flybridge Hardtop
- Hydraulics - Stern thruster - Hydraulic (65hp)
- Hydraulics - Trac Star Digital fin stabilizer system
- MPA Tisseen Monitoring System 15\" touch screen display
- MPA Monitoring - 15\" touch screen display in Crew Mess
- MPA Monitoring - CCTV system with four cameras and dedicated display in crew mess connected to Tisseen system
- MPA Monitoring - Generator Control and Monitoring System Upgrade Additional system feature allowing complete control and monitoring of generator parameters and alarms via MPA Touch Screen
- MPA Monitoring - Handheld wireless tablet display
- MTU 4000 series toolkit with stowage in engine room
- Passerelle Upgrade - Stainless Steel Finish
- Polished Stainless Steel Anchors
- Retractable Electric Sun Awning for mid-deck overhang
- Retractable Electric Sun Awning for Flybridge Bar Area
- Flir camera night watch
- Security alarm system
- Sewage Treatment Plant (interfaced to Tisseen System)
- Sunshade - Additional stainless steel socket for sunshade listed below
- Sunshade - Square type three-metre sunshade for use as parasol including one stainless steel socket
- Teak Forepeak deck area and Flybridge Deck
- Tender 6m Pascoe 6.0 m
- Trailing for engines
- Wind system to be connected to Central Navigation Display
- Under Water Lights - 5 x Large Xenon (3 across the transom and 1 aft either side)
- Automatic Main Saloon doors
- Cleats - Second pair of cleats at the bow
- Tinted film to side windows and sliding doors
- 3rd generator (night generator-silent) with separate underwater exhaust
- Bow fairleads with rollers in order to save rope wear
- Tool stowage to have space
- Compressor air system
- Central display upgrade to 21\"
- Radar display upgrade to 21\"
- Chartplotter display upgrade to 21\"
- SAT TV with receiver on each TV
- SAT Thrane & Thrane phone system doom to match SAT TV doom
- Notice* All areas apart crew mess, crew and captain cabins to have B&O TV\'s and surround systems apart from main salon
- Table and chairs on fly-bridge
- Diver\'s compressor
- Yacht name written in stainless steel with LED diodes
- MTU Blue Line controls in engine control room
- (4) Deck chair on fly-bridge
- Headroom: 7\'2\" 2.1m
- Hardtop: GRP with BESENZONI retractable canopy
- Decks: Teak planking 12mn expect flybridge 9mn
Security
- CCTV System (cameras): 1 Port side facing forward, facing aft, 1 Starboard side deck, forward-facing aft, 1 Main Deck Aft Cockpit, 2 Engine Room, 1 Tender Garage
- Full 15’’ M.P.A Master Touchscreen display in crew mess
- Navigation parameter interface allowing NMEA data to be displayed on the M.P.A screens
- Primary M.P.A Touchscreen (2) Electrical Main and Wheelhouse
- Slave M.P.A Touchscreen (2) Engine Room and Crew Mess
- Tisseen System: Monitoring all system on yacht (electric power, generators, water, outside light)
Safety and Life Saving equipment (LY2)
- Life rafts: (4) ZODIAC (10 men) XTREM 2010 10 MANSART
- Life Buoys: (2) 4kg & (2) 2.5kg
- Life Jackets: 22 Complete with retro-reflective tape and lights adult
- Life Jackets Child: 2
- Water Sports Buoyancy aids: 6
- Grab Bags: 2 SOLAS B
- MOB smoke & light: 2
- Buoyant Line: 2
- Set of line throwers: 1
- Rocket flares: 6
- Flare polybottle: 1
- Axis 30 VHF emergency radio: 2
- Axis 30 Spare testing battery: 2
- (6kg Powder, 9ltr Foam, 5kg CO2, Spare powder Cartridge, Spare Powder, Sapre Foam Cartridge, Sapre Foam Compound)
- Cat C Medical kit for 20 persons (positioned under the captain’s bunk)
Firefighting Equipment
- Smoke detectors/ heat Sensors: In all cabins
- Fixed CO2 Fire System: (2) Electrical Room
- High Fog System: Garage/Engine Room
- Sprinkler System: (2) Garage Sprinkler
- Fire Extinguishers: (2) FM 200 Fire Engine Room/ Electrical Room; (2) Portable Co2 in the Engine Room; (1) Portable Co2 in the Electrical Room; (6) Powder in the engine Room; (1) Powder in the Electrical Room; Fire fighting: (2) Asbestos Suit
- Smoke detector alarms: Machinery spaces with heat detector alarms
Fire & Bilge System
- Primary Fire & Bilge pump: 400 V A.C 5.5kW 50/60Hz 3 phase – self priming – Circa 45m3/hr - (Approx 12.5l/sec) @ 10m head in the engine room
- Secondary Fire & Bilge pump: Coupled to a manual start diesel engine – capacity of circa 40m3/hr (approx 11l/sec) @ 10m head in a dedicated pump room
- Emergency Bilge pump: Engine driven – self priming
- Main Tender: 6 Meters PASCOE YANMAR 180HP Jet
- Dive Compressor: BAUER Junior II dive compressor
- RINA cleaning and painting tanks: water, sanitary, fuel
- RINA SOS radio batteries
- RINA \"MEGGER TEST\" Insulation resistance test report for all 220 systems.
- RINA Radio contract
- RINA Generator - replacement of two magnetic parts
- RINA bottom and fire pump service
- RINA Fire Equipment Inspection
- RINA Rescue Equipment Inspection
- RINA generators - inspection \"KOHLER\" three units
- RINA dry dock - antifouling paint
- RINA material paint Antifouling coating HEMPEL 7110P
- RINA disassembly/assembly of propellers, gearboxes, and shafts. (wear, cracks)
- RINA inspection of anchor chains (wear no more than 12% of the diameter)
- RINA dismantling/assembly and inspection of magnetic tapered shaft parts
- RINA dismantling/installation of bottom valves for visual inspection
- RINA purchase and replacement 3 bottom valves (DN 125 DN 150)
- RINA test of all systems of navigation systems, fire, and emergency
- Epoxy painting of black and water tanks
- Fiber enforcement of the walls where the central bottom filters are installed
- Teak work
- Underwater Zinc replacement
- Platform Hydraulic Cylinder replacements and service
- RINA MTU - change of oil and filters current technical maintenance and issuance of certificates
- RINA MTU - battery test
- Replacing the head motor batteries
- Replacing emergency lamp batteries (engine room)
- Purchase of a new GPS satellite transmitter
- Bottom Diesel Pump Service
- Polishing the superstructure
- Service Hydraulic balconies
- Professional interior cleaning and disinfection
- Tender serviced
- Polishing front glass
- Cleaning all the water tubes
- Air-condition pumps serviced
- Water pumps serviced
- All RINA certificates are issued and up to date
